可见光LED Visible LED - 照明(Lighting LED)
> 5630D HE Package (0.2W) |
| |
|
 |
5630D HE Package (0.2W)
The Everlight 0.2W 62-217D package has high efficacy, high CRI, low power consumption, wide viewing angle and a compact form factor. These features make this package an ideal LED for all lighting application. |
| |
|
 特性 |
PLCC-2 Package
Top view white LED
High luminous flux output
High current capability
High Efficiency
Wide viewing angle
Pb-free
RoHS compliant
ANSI Binning
|
|
應用 |
Decorative and Entertainment Lighting
Light pipe application
Indicator and backlight in office and family equipment
General use
|
| |
|
|
|
|
| |
| 规格 |
|
| P/N |
Dimension (mm) |
Power(W) |
Forward Voltage (V) |
Forward Current (mA) |
CCT(K) |
Luminous Efficacy(lm/W) |
Datasheet |
| 62-217D/KK4D-M6565X0Y02532U6/2T/EU |
5.6x3.0x0.65 |
6500K |
32 |
80 |
2.5~3.2 |
|
 |
| 62-217D/KK5D-M2727X0Y02530U6/2T |
5.6x3.0x0.65 |
3000K |
31 |
80 |
2.75 |
|
|
| 62-217D/KK5D-M3030X1Y12530U6/2T |
5.6x3.0x0.65 |
3000K |
32 |
80 |
2.75 |
|
|
| 62-217D/KK5D-M4040X2Y22530U6/2T |
5.6x3.0x0.65 |
4000K |
33 |
80 |
2.75 |
|
|
| 62-217D/KK5D-M5050X3Y32530U6/2T |
5.6x3.0x0.65 |
5700K |
34 |
80 |
2.75 |
|
|
| 62-217D/KK5D-M5757X3Y32530U6/2T |
5.6x3.0x0.65 |
5700K |
34 |
80 |
2.75 |
|
|
| 62-217D/KK5D-M6565X2Y22530U6/2T |
5.6x3.0x0.65 |
5700K |
33 |
80 |
2.75 |
|
|
|
| |
